AC Accelero Xtreme Plus

AC Accelero Xtreme Plus

UPOZORNENIE: Samotný Xtreme Plus neobsahuje kompatibility kit s VR and RAM chladičom,  nezabudnite si ho priobjednať!!!
Alebo si zvoľte SET s príslušnou verziou kompatibility kitu označenou ako Extreme Plus VR001 - VR005....


Kompatibilné kity:
VR001 - ATI Radeon 6970,6950,6870,5870, 5830, 4890, 4870, 4850, 4830, 3870, 3850, nVIDIA GeForce GTS 250, 9800GTX+, 9800GTX, RAM and voltage regulator heatsinks set, thermal adhesive
VR002 - nVIDIA GeForce GTX 285, 280, 275, 260+, 260 Mounting plate, RAM, voltage regulators, and NVIO chipset heatsinks set, thermal adhesive
VR003 - nVIDIA GeForce GTX 470, 465 Mounting plate, RAM and voltage regulators heatsinks set, thermal adhesive
VR004 - VIDIA GeForce GTX 580, 570, 480  Mounting plate, RAM and voltage regulators heatsinks set, thermal adhesive
VR005 - nVIDIA GeForce GTX 460, 560 Ti   Mounting plate, RAM and voltage regulators heatsinks set, thermal adhesive


Promising Results in the Accelero XTREME Series
The Accelero XTREME Plus is a multi-compatible cooler for high-end VGA boards. While high-end VGA stock coolers are usually noisy and inefficient, ARCTIC develops the Accelero XTREME Plus, a much more effective inaudible cooling solution, for users to replace those stock coolers.

Main features
Unmatched cooling performance – 250 Watts – for a multi-compatible VGA cooler
3 ultra quiet 92mm PWM fans with low noise impeller
5 heatpipes and 84 fins for efficient heat dissipation
Patented fan holder eliminates buzzing and vibrating sound
Pre-applied ARCTIC MX-4
Compatible with CrossFire and SLI

An Extension of Accelero XTREME Series
Another key feature in the Accelero XTREME Plus is its interchangeable mounting plate for vast compatibility for new or yet to be released graphic cards. Along with the Accelero XTREME Plus, users need to purchase and install a set of accessories with their cooler, including a mounting frame, thermal glue, heat sinks for RAM coolers, and heat sinks for voltage regulators1.

Rather than having several VGA coolers designated for specific graphic cards, ARCTIC develops this generic model of cooler and various accessory sets to make the cooler compatible with different VGA boards. As new VGA cards are released, ARCTIC will design and release new fittings; hence this makes the Accelero XTREME Plus very versatile for overclockers to upgrade their computers frequently. This also helps overclockers to provide quick and effective cooling solution for new graphic boards.

The Engineering Design
Since the fan models in the Accelero XTREME series have proven to be inaudible and effective, the Accelero XTREME Plus adopts a similar design. The three 92mm PWM fans run from 900-2000 RPM to generate enough airflow to dissipate heat quickly from the GPU.

The cooling performance and noise level in the Accelero series offers promising results. When the Accelero XTREME Plus is used with ATI Radeon HD 5870 graphic card, the noise level is 0.5 sone with temperature maintaining at 41°C at 2000 RPM. However, when the stock cooler runs at the same speed, it is 3.5 sone with temperature at 77°C. With this comparison, it is evident that Accelero XTREME Plus manages to reduce temperature effectively at minimum noise level. The patented fan holder on this cooler also plays a prominent role in reducing noise to a minimum level as it eliminates the vibrating sound of the fan with the frame.

With the proven engineering design in Accelero XTREME Plus along with its new multi-compatibility with many VGA boards, overclocking can be maximized. The Accelero XTREME Plus can for sure enhance overclocking performance and also extend service life of VGA board as well.

Dimensions    290 L x 104 W x 56 H mm
Fan   92mm x 3 fans with 120mm cable
Fan speed   900 - 2000 RPM (controlled by PWM)
Air flow   81 CFM / 138m3/h
Max. Cooling Capacity   250 Watts
Bearing   Fluid Dynamic Bearing
Weight   622g

Important notice
The Accelero XTREME Plus does not have any additional heatsinks for VR and RAM.
To use the cooler on a VGA board it needs to be purchased with a specific set of heat sinks. Please find the according sets underneath.
