AEROCOOL LS-5200 White

AEROCOOL LS-5200 White

Špičkový miditower připravený na instalaci až dvou výměníků vodního chlazení a nebo až 6 ventilátorů pro dokonalé chlazení.

FAN SPEED CONTROL
Built-in two fan controller switches.
2 x USB2.0 + 1 x USB3.0 + HD Audio & Mic + Power button.

ULTRA-AIR COOLING
Huge air intake from the front panel .
Superb airflow system install up to 6 fans

DUAL WATER-COOLING
Supports either 280mm or 360mm water cooling system on front panel.
Supports either 240mm or 280mm water cooling system on top panel.

SPACIOUS INTERIOR
Install either 4 x 2.5" HDD/SSD and 3 x 3.5" HDD on side space.

SPECIFICATION



Model Name LS-5200
Case Type Mid Tower for water cooling
Steel Thickness 0.6mm
Motherboards ATX / micro ATX / mini-ITX
Chassis Dimensions 220 x 460 x 376.5 mm (W x H x D)
3.5"Drive Bays 3 + 2 (2.5/3.5 HDD Cage)
2.5"Drive Bays 2 + 4 (2.5/3.5 HDD Cage)
Expansion Slots 7 Slots
Max length space available for PCI slots 346 mm / 371mm (without front fan)
I/O Ports 2 x USB2.0 + 1 x USB3.0 + HD Audio & Mic.
Height limit for CPU coolers Support Max. Height of 170 mm For CPU
Cooling System
Front : 3 x 120mm or 2 x 140mm (Optional)

Top: 2 x 120mm or 2 x 140mm (Optional)

Rear : 1 x 120mm or 1 x 140mm fan (120mm Included)

Radiator Support
Front : 3 x 120mm or 2 x 140mm (Optional)

Top: 2 x 120mm or 2 x 140mm (Optional)

Rear : 1 x 120mm (Optional)

Net Weight 5.5Kg (GW:6.5Kg)
Power Supply ATX PSU (Optional)


COOLING SYSTEM

LS-5200 [ Rear ]
Black Edition


Fan 120 x 120 x 25 mm
Rated voltage 12V
Operating Voltage Range 6.0~13.2V
Starting voltage 6V
Rated current 0.12A+-10%Max
Power consumption 1.44W+10%Max
Speed 1200+-10%RPM
Max AirFlow(CFM) 36.4CFM
Max Static Pressure 1.32mm-H2O
Noise (dBA) 26.5dBA
MTBF 20,000 hours
