Zyxel VPN 1000 Firewall Appliance 12 GbE Copper/2 SFP, 8000 Mbit/S Firewall Throughput, 1000 IPSec VPN Tunnels

Zyxel VPN 1000 Firewall Appliance 12 GbE Copper/2 SFP

Hardware Specifications
Interfaces 12 x GbE (Configurable) 2 x SFP
USB3.0 ports 2
Console port Yes (DB9)
Rack-mountable Yes
System Capacity & Performance*1
SPI firewall throughput (Mbps)*2 8
VPN throughput (Mbps)*3 1,5
Max. TCP concurrent sessions*4 3,000,000
Max. concurrent IPSec VPN tunnels*5 1
Concurrent SSL VPN users (default/max.)*6 250/500
VLAN interface 128
Concurrent device logins (default/max.)*6 800/4000
WLAN Management
Managed AP number (default/max.)*6 8/1032
Key Features
VPN IKEv2, IPSec, SSL, L2TP/IPSec
SSL (HTTPS) inspection Yes
Content filtering*6 1 year free
Geo Enforcer*6 1 year free
EZ Mode -
Hotspot Management*6*7 Yes
Ticket printer support*7 / Support Q'ty (max.) Yes (SP350E) / 10
Amazon / Azure VPC Yes
Facebook WiFi Yes
Device HA Pro*8 Yes
Power Requirements
Power input 100-240 V AC, 50/60 Hz,2.5 A max.
Max. power consumption (watt) 46.0
Heat dissipation (BTU/hr) 120.10
Physical Specifications
Item Dimensions (WxDxH)(mm/in.)
400 x 250 x 44/16.93 x 9.84 x 1.73
Weight (kg/lb.)
3.3/7.28
Packing Dimensions (WxDxH)(mm/in.)
519 x 392 x 163/20.43 x 15.43 x 6.42
Weight (kg/lb.)
4.8/10.58
Included accessories
Power cord
Rack mounting kit
Environmental Specifications
Operating Temperature
0°C to 40°C /32°F to 104°F
Humidity
10% to 90%(non-condensing)
Storage Temperature
-30°C to 70°C (-22°F to 158°F)
Humidity
10% to 90%(non-condensing)
MTBF (hr) 444,93
Certifications
EMC FCC Part 15 (Class A),CE EMC (Class A),C-Tick (Class A),BSMI
Safety LVD (EN60950-1), BSMI
* This matrix with the latest firmware version.
1. Actual performance may vary depending on network conditions and activated applications.
2. Maximum throughput based on RFC 2544 (1,518-byte UDP packets).
3. VPN throughput measured based on RFC 2544 (1,424-byte UDP packets).
4. Maximum sessions measured using the industry standard IXIA IxLoad testing tool.
5. Including Gateway-to-Gateway and Client-to-Gateway.
6. With Zyxel service license to enable or extend the feature capacity.
7. With Hotspot Management license support.
8. ZyWALL VPN100 or above supports Device HA Pro once registered.
