ASUS PRIME Z490-A

Chipset: Intel® Z490 Rozměrový formát: ATX Form Factor (305 mm x 244 mm) Podpora pro procesory: Intel® Socket 1200 for 10th Gen Intel® Core™, Pentium® Gold and Celeron® Processors Patice procesoru: LGA 1200 Pozice na paměti: 4x DDR4 DIMM Podpora pro paměti: 4800(O.C.)/4600(O.C)/4500(O.C)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3333(O.C.)/3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz Non-ECC, Un-buffered Memory Max.velikost operační paměti: 128 GB Podpora pro paměti typu: DDR4 (Dual Channel) Grafická karta: Integrated Graphics Processor (na základě CPU) Multi GPU: *NVIDIA 2-Way SLI® Technology *AMD 3-Way CrossFireX™ Technology Zvuková karta: *Realtek ALC S1220A 7.1 Surround Sound High Definition Audio CODEC Síťová karta: *Intel® I225-V 2.5Gb Ethernet (ASUS LANGuard) Rozšiřující sloty: *2x PCIe 3.0 x16 (x16 or dual x8) *1x PCIe 3.0 x16 (max at x4 mode) *3x PCIe 3.0 x1 RAID řadič: 0, 1, 5, 10 SATA: *6x SATA 6Gb/s port(s) M.2: *1x M.2_1 socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode) *1x M.2_2 socket 3, with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode) USB: *zadní USB porty ( celkem 8 ) *4x USB 3.2 Gen 2 port(s)(3 x Type-A +1 x USB Type-C®) *2x USB 3.2 Gen 1 port(s)(2 x Type-A) *2x USB 2.0 port(s)(2 x Type-A) *přední USB porty ( celkem 7 ) *1x USB 3.2 Gen 2 front panel connector port(s) *2x USB 3.2 Gen 1 port(s) *4x USB 2.0 port(s) Interní porty: *1x CPU Fan connector(s) *1x CPU OPT Fan connector(s) *2x Chassis Fan connector(s) *1x AIO_PUMP connector *1x W_PUMP+ connector *1x AAFP connector *2x Aura RGB Strip Headers *2x Addressable Gen 2 header(s) *1x USB 3.2 Gen2 connector support additional 1 USB ports(20-pin, Type-C) *1x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s) *2x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s) *1x M.2 Socket 1 with M Key, type 2242/2260/2280/22110 storage devices support (SATA mode & PCIE mode) *1x M.2 Socket 2 with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode) *1x M.2 with E key for Wi-Fi module *1x COM port(s) connector(s) *6x SATA 6Gb/s connector(s) *1x Thunderbolt header(s) *1x 24-pin EATX Power connector(s) *1x 8-pin ATX 12V Power connector(s) *1x 4-pin ATX 12V Power connector(s) *1x System panel(s) (Chassis intrusion header is inbuilt) *1x Thermal sensor connector(s) *1x Power-on button(s) *1x Clear CMOS jumper(s) *1x CPU_OV jumper *1x M.2 Fan Header Externí porty: *1x Intel® I225-V 2.5Gb Ethernet *1x DisplayPort *1x HDMI *4x USB 3.2 Gen 2 (3 x Type-A+1 x USB Type-C®) *2x USB 3.2 Gen 1 *2x USB 2.0 *1x Optical S/PDIF out *5x Audio jack(s) Obsah balení: *Uživatelská příručka *3x SATA 6Gb/s cable(s) *1x Supporting DVD *1x Q-Connector *1x CPU Fan Holder *1x M.2 SSD screw package(s) *1x M.2 Key E screw package(s) *1x M.2 Rubber Package(s) BIOS: 192 (128+64) Mb Flash ROM, UEFI AMI BIOS Stránka výrobce: https://www.asus.com/Motherboards/PRIME-Z490-A/
