DeLock PCI řadič 2x SATA + 1x IDE, RAID

DeLock PCI řadič 2x SATA + 1x IDE

SATA1 2x interní, ATA133 1x interní
- VIA Chipset VT6421A
- PCI
- podporuje RAID 0,1 mezi IDE disky, mezi SATA disky i mezi IDE a SATA diskem
- certifikován IBM pro servery České pošty (IBM code EHBA46C0993)

The Delock Controller card has to be plugged internal to the PCI slot. You can connect hard
disks, CD-ROM drives or other devices to the controller card. Due to the Raid function you can
connect multiple hard disks logical and raise the data security, the speed or capacity.


Specification
• 2x SATA I specification
• 1x PATA IDE specification
• Data transfer rate: SATA up to 1.5 Gbps
                               PATA up to 133 Mbps
• 32-Bit PCI standard 2.2
• Supports up to 2 HDDs on the SATA controller as well as 2 HDDs on the IDE controller
• Supports Hard disks more than 137 GB
• Raid 0, 1, 0+1, JBOD
• Plug & Play
• For Windows 98/ME/NT/2000/XP/XP-64/Server 2003, Linux ex Kernel 2.6, win 8

System requirements
• PC with one free PCI Slot
• Windows 98/ME/NT/2000/XP/XP-64/Server 2003, Linux ex Kernel 2.6

Package content
• Controller card
• Driver CD
• User manual

Package
• Blister
