Linksys RE1000 Wireless-N Extender

Linksys RE1000 Wireless-N Extender

   The newest way to expand your wireless network
   Extend the wireless signal of your Access Point or Router
   Provide Internet connectivity in hard to reach areas via a wired or wireless connection

Specifications:

Model Name Linksys RE1000
Model Description Wireless-N Extender

   Standards

IEEE 802.11n, 802.11g, 802.11b, 802.3u
Ports Fast Ethernet, C7 connector for localized AC cable or clip
Buttons Reset, Wi-Fi Protected Setup™
LEDs Backlit Cisco logo, Ethernet(active, traffic)
Cabling Type CAT 5

   Antennas 2 (internal)

Detachable (y/n) No

   Transmitted Power

802.11n (40MHz) 15.5 ± 1.5 dBm @ CH6, mcs15
802.11n (20MHz) 17.0 ± 1.5 dBm @ CH6, mcs0-4, mcs8-12
802.11n (20MHz) 16.0 ± 1.5 dBm @ CH6, mcs5-7, mcs13-15
802.11g 18.0 ± 1.5 dBm
802.11b 18.0 ± 1.5 dBm

   Receive Sensitivity

-91 dBm @ 1 Mbps
-87 dBm @ 11 Mbps
-71 dBm @ 54 Mbps
-66 dBm @ 270 Mbps

   Antenna Gain 3.5 dBi
   Wireless Security Wi-Fi Protected Access™ 2 (WPA2), WEP Security Key Bits Up to 128-Bit Encryption
   Environmental

Dimensions 4.92” x 3.62” x 1.29” (125 x 92 x 33 mm)
Weight 9.9 oz (280 g)
Power Internal AC/DC power supply 100-240V, 50/60Hz, 0.5A

Certification FCC, UL/cUL, ICES-003, RSS210, CE, Wi-Fi a/b/g/n, Wi-Fi (IEEE802.11b/g/n), WPA2™, WMM®, Wi-Fi Protected Setup™
Operating Temp. 32 to 104°F (0 to 40°C)
Storage Temp. -4 to 140°F (-20 to 60°C)
Operating Humidity 10 to 80% Noncondensing
Storage Humidity 5 to 90% Noncondensing
