Intel Xeon E5-2637V3, 3.5 GHz, TRAY

Intel Xeon E5-2637V3

Launch Date Q3'14
Processor Number E5-2637V3
Intel® Smart Cache 15 MB
Intel® QPI Speed 9.6 GT/s
# of QPI Links 2
Instruction Set 64-bit
Instruction Set Extensions AVX 2.0
Embedded Options Available No
Lithography 22 nm
Scalability 2S
VID Voltage Range 0.65V–1.30V
Recommended Customer Price TRAY: $996.00
Datasheet Link
Product Brief Link
Additional Information URL Link
-Performance
# of Cores 4
# of Threads 8
Processor Base Frequency 3.5 GHz
Max Turbo Frequency 3.7 GHz
TDP 135 W
-Memory Specifications
Max Memory Size (dependent on memory type) 768 GB
Memory Types DDR4 1600/1866/2133
Max # of Memory Channels 4
Max Memory Bandwidth 68 GB/s
Physical Address Extensions 46-bit
ECC Memory Supported ‡ Yes
-Graphics Specifications
Processor Graphics ‡ None
-Expansion Options
PCI Express Revision 3.0
PCI Express Configurations ‡ x4, x8, x16
Max # of PCI Express Lanes 40
-Package Specifications
Max CPU Configuration 2
TCASE 76.6°C
Package Size 52.5mm x 45mm
Sockets Supported FCLGA2011-3
Low Halogen Options Available See MDDS
-Advanced Technologies
Intel® Turbo Boost Technology ‡ 2.0
Intel® vPro Technology ‡ Yes
Intel® Hyper-Threading Technology ‡ Yes
Intel® Virtualization Technology (VT-x) ‡ Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes
Intel® VT-x with Extended Page Tables (EPT) ‡ Yes
Intel® TSX-NI No
Intel® 64 ‡ Yes
Idle States Yes
Enhanced Intel SpeedStep® Technology Yes
Intel® Demand Based Switching Yes
Thermal Monitoring Technologies Yes
Intel® Flex Memory Access No
Intel® Identity Protection Technology ‡ No
-Intel® Data Protection Technology
Intel® AES New Instructions Yes
Secure Key Yes
-Intel® Platform Protection Technology
OS Guard Yes
Trusted Execution Technology ‡ Yes
Execute Disable Bit ‡ Yes
